Interfacing Lutron RadioRA 2® Systems with HoneywellVista-128BPTSecurity Systems

revision A

Interfacing Lutron RadioRA 2® Systems with

Honeywell Vista-128BPTSecurity Systems

Overview

RadioRA 2® is capable of direct integration with the HoneywellVista-128BPTsecurity panel. Integrating RadioRA 2 with a security system enables many new features beyond intrusion alert. By incorporating lighting control, shades, temperature, and small appliance control, RadioRA 2 offers energy savings, convenience, and ambiance that the homeowner can enjoy every day.

Required components

In order to interface RadioRA 2 with a Vista-128BPTsecurity panel, you will need the following items:

∙RadioRA 2 system installed

∙RadioRA 2 programming software version 5.0 or higher.

∙Honeywell Vista-128BPTsecurity panel installed and programmed (to enable the extra settings to allowintegration—notcovered in the Honeywell instructions—seeAppendix 2)

∙Null Modem Serial cable or straight-throughSerial cable with a Null Modem adapter

Wiring

Programming Overview

Programming a RadioRA 2 system to interface with a Honeywell Vista-128BPTsecurity panel is done in four phases:

1.) Install and program the Honeywell Vista-128BPTsecurity system according to Honeywell instructions.

2.) Program the Vista-128BPTto enable the extra settings to allow the integration, not covered in the Honeywell instructions (see Appendix 2).

3.) Install and program the Lutron RadioRA 2 system using RadioRA 2 programming software version 5.0 or higher. 4.) Program appropriate phantom buttons associated with each security action, as described in the following section.

Programming Phantom Buttons for Security

Actions in the Honeywell Vista-128BPTsecurity panel will sendRS-232commands to the RadioRA 2 system. Each command is associated with a specific phantom button, and each phantom button may be programmed to deliver a desired scene. When a command is received from the security system, the corresponding phantom button is automatically “pressed”. For certain buttons, a Time of Day feature has beenpre-programmedso that the most appropriate action takes place.

The RadioRA 2 Main Repeater has 100 phantom buttons available for use with integration. Buttons 76-100are configured to receive commands from the Honeywell Vista Turbo system. Table 1 shows how each security action is associated with RadioRA 2 phantom buttons and Table 2 offers a recommended scene for each phantom button. The Time of Day, when various actions will take place, is also specified. Table 3 provides a timeline illustrating how the RadioRA 2 system will automatically respond to various security commands throughout the day.

Note: If the HoneywellVista-128BPTsystem has no partitions, use phantom buttons associated with partition 1. See Table 2 for the phantom button to partition mapping.

Table 1: Security Actions and associated Phantom Buttons (Partition 1)

This table illustrates the various possible actions from a security system and the phantom buttons they will activate depending on Time of Day. The recommended phantom button scene name is also matched to the phantom button number.

Table 2: Phantom Buttons and Recommended Programming

This table provides the recommended programming for each phantom button associated with security on the Main Repeater.

Ademco Programming Software

Table 3: Security Programming Timelines

When configured according to this tech tip, the RadioRA 2 system will automatically respond to commands from the security keypad as outlined in the tables below.

Appendix 1: Programming the Phantom Buttons

Coming soon: for more in-depthprogramming instructions, a corresponding Security Training Module can be found online atresi.lutron.com/radiora2 by following the RadioRA 2 Software Online Training Modules link.

1

Compass Programming Software Ademco V…

2

Once the project has been designed in the RadioRA 2 programming software, select the “Program” tab (1) and then find the Main Repeater using the “Selected Device Location”drop-downmenu (2).

3

Next, select the desired button from the “Phantom Button” drop-downmenu (3).

5

4

Finally, choose the appropriate “Selected Button Type” (4) and program devices and levels (5).

Remember: you must also complete the activation and transfer steps for the programming to take effect

Appendix 2: Serial Programming Options for Automation Applications

The following group of fields must be set to use the serial port for automation applications:

•*05 Enter 1 to send System Event Messages via RS232 port

•*14 Enter 0 to disable Home/Facility Automation Control Input

•1*70 Event Log Types (Enter 1 in each event log type)

•1*78 Extended Home Control Events (Enter 1 for extended)

•1*79 Home Control Event Types (Enter 1 in each home control event type)

•1*80 Enter 1 to improve automation performance by disabling fault/restore messages over the automation port.
